CONNECT DOCKING STATION TO
TV OR VCR
Connect as shown in the illustration
(੬ pg. 58).
If using a VCR . . . go to step 2.
If not . . . go to step 3.
2
CONNECT VCR OUTPUT TO TV
INPUT
Refer to your VCR’s instruction manual.
3
TURN ON POWER
4
SELECT TV’S VIDEO MODE
Set the TV to the channel or mode appropriate
for video playback.
NOTES:
●
When using the provided VIDEO/AUDIO cable
(Docking Station to TV or VCR), DC cord, S-
VIDEO cable or editing cable, make sure you
connect the end of the cable with the core filter to
the Docking Station. The core filter improves
performance of equipment.
●
If TV/VCR is equipped with only one audio
connector, use a conversion plug (commercially
available).
●
If the TV or VCR has an S-Video input terminal,
connect it using an S-Video cable.
