FORTRA
Force
4
G6 Installation Guide Rev B
2-1
This chapter covers specification information for the FORTRA
FFoorrccee
44
G6 RAID
System enclosure.
Environmental Specifications
Operating Temperature: 5°C to 40°C (41°F to 104°F)
Storage Temperature: 0°C to 65°C (32°F to 149°F)
Maximum ambient temperature is dependent on the recommended temperature to
meet the MTBF rating as specified by the manufacturer of the installed devices.
Electrical Specifications
AC Inlet Type: IEC320/EN60320
Power Cord: NEMA5-15P
Power Supply: Auto-switching for 110/220V operation
Agency Compliance
FORTRA
enclosures have been designed and built to comply with the FCC
Class A, UL, CSA/TUV, CE, and C-Tick standards. For more information on
FCC Class A compliance, see page 2.
Packaging Specifications
FORTRA
packaging has been designed to be reusable and recyclable. Drives
may be installed and shipped in the canisters as long as the canisters are in their
original packaging location and are not installed in the enclosure. Shipping the
unit with canisters and/or power supplies installed in the enclosure may cause
damage to the enclosure or to the drives and will void the warranty.
Packaging complies with ISTA (International Safe Transit Association) standards
and has been ISTA certified.
Each canister is pre-packaged in an anti-static bag. Do not throw the packaging
away if the product is intended for re-shipping. When transporting or shipping a
JMR approved shipping container must be used.
SAFETY TIP: Reshipping the enclosure with canisters, drives, or power
supplies installed in the enclosure may cause damage to these
components and will void the warranty
SICHERHEITSHINWEIS: Der Versand des Gehäuses mit eingebauten
Einschüben, Platten und Netzteilen kann zur Beschädigung dieser
Komponenten führen und somit den Garantieanspruch gefährden.
2. Hardware Specification
