HP SC40Ge SAS Host
Bus Adapter with RAID
RAID Support
RAID 1 (Mirroring)
RAID 0 (Striping)
Logical Drives
Supported
Up to 2 Logical Volumes
Up to 10 drives total in all RAID volumes
Up to 2 Drives per RAID 1
Up to 8 Drives per RAID 0
Maximum Capacity
3.6TB (8 x 450GB)
Data Transfer Method
PCI-Express x8 - 2 GB/s maximum bandwidth
Port Transfer Rate
12 Gb/s per x4 Wide SAS Port (4 x 3 Gb/s)
Simultaneous Drive
Transfer Ports
2 x4 Wide SAS Connectors
Protocols
3 Gbps SAS and 1.5 Gbps SATA
1.5 Gbps SATA (Serial Advanced Technology Attachment)
External SAS
Connectors
None
Internal SAS
Connectors
2 internal SFF8484 x4 SAS Connectors
Upgradeable Firmware
4MB flashable ROM
HP E200/128 BBWC
Smart Array Controller
Dimensions
(excluding
bracket)
6.6 x 2.5 x 0.6 in (16.8 x 6.4 x 1.6 cm)
Disk Drive and
Enclosure Protocol
Support
3 Gbps SAS (Serial Attached SCSI)
1.5 Gbps SATA (Serial Advanced Technology Attachment)
Architecture
64-bit
SAS Connectors
2 internal SFF8484 x4 Wide SAS Connectors
12 Gbps per x4 Wide SAS Port (4 x 3 Gbps)
Data Transfer Method
PCI-Express x8 - 2 GB/s maximum bandwidth
PCI Bus Speed
PCI-Express x8
Simultaneous Drive
Transfer Ports
2 x4 Wide SAS Connectors
Port Transfer Rate
12 Gb/s per x4 Wide SAS Port (4 x 3 Gb/s)
Software upgradeable
Firmware
Yes
Maximum Capacity
3.6TB (8 x 450GB)
Memory Addressing
64-bit, supporting servers memory greater than 4 GB
Logical Drives
Supported
<FILL IN>
RAID Support
RAID 1 (Mirroring)
RAID 0 (Striping)
RAID 5
Upgradeable Firmware
4-MB flashable ROM
Disk Drive and
Enclosure Protocol
Support
3 Gbps SAS and 1.5 Gbps SATA
QuickSpecs
HP ProLiant ML110 Generation 5
Technical Specifications
DA - 12867 Worldwide QuickSpecs — Version 10 — 4.18.2008
Page 26
