18 P61A!!Pellet!Stove
The!room!sensor!is!a!small!temperature!sen-
sor!on!the!end!of!a!60"!gray!wire.!This!sensor!is
installed!much!like!a! standard !wall!thermostat.!Be-
cause!it!is!so!small,!it!can!be!hidden!along!the!trim
of!a!doorway!or!even!up!the!leg!of!a!coffee!table.
There!is!a!remote!room!sensor!port!on!the!rear!of
the!unit!for!easy!external!connection.!Use!standard
18-2!thermostat!wire!to!extend!the!distance!to!the
desired!location!(100'!!maximum).!The!room!sen-
sor!should!be!installed !in!the!location!where !you!want
to!control!the!temperature.
NOTE:!Distances! of!more!than! 25!feet!from
the!unit!or!in!another!room!are!not!recommended.
The!room!sensor!is!essential!for!the!P61A's!excel-
lent!efficiency.
NOTE:! It! is! recommended! that! the! room
sensor!be!installed,!even!if!only!installed!on!the
rear!of!the!unit!as!a!return!air!sensor.
Fig.!24
Room! Sensor! Installation
Fig.!25
Room!Sensor!and!Rear!Shield!Installation
Rear! Shields
5/16"!Hex!Head
Screws!(2!on
each!side)
5/16"!Hex
Head
Screws!(2
on!each
side)
The!rear!isolated!shields!are !split! in!the!middle!for
easy!removal.!Each!shield!has!two!5/16"!hex!head
screws! that! only! need! to! be! loosened! (NOT
REMOVED)!to!allow!the!shield!to!slide!away!from
the!unit.!NOTE:!It!is!not!recommended!that!the
unit!be!operated! with!the!shields!removed,!due
to!the!hot!and!moving!parts!which!they!protect.
