EPSON Stylus Photo 750 Revision A
Product Description General Description 11
1.2.8 Input Data Buffer
†
Buffer: 256 Kbytes
1.2.9 Electric Specification
†
120V version
„
Rated voltage: AC 120V
„
Input voltage range: AC 99 -132V
„
Rated frequency range:50 - 60Hz
„
Input frequency range:49.5-60.5 Hz
„
Rated current: 0.4A(Max.0.5A)
„
Power consumption: Approx.18W(ISO/IEC 10561 Letter
pattern) Energy Star compliant
„
Insulation Resistance:10 M ohms min. (between AC line and
chassis, DC 500V)
„
Dielectric: AC 1000 V rms. 1 minute or
AC 1200 V rms 1 second(between AC
line and chassis)
†
220-240V version
„
Rated voltage: AC220-240V
„
Input voltage range: AC 198 -264V
„
Rated frequency range: 50 - 60Hz
„
Input frequency range:49.5-60.5 Hz
„
Rated current: 0.2A(Max.0.3A)
„
Power consumption: Approx.18W(ISO/IEC 10561 Letter
pattern) Energy Star compliat
„
Insulation Resistance:10 M ohms min. (between AC line and
chassis, DC 500V)
„
Dielectric: AC 1500 V rms. 1 minute (between AC
line and chassis)
1.2.10 Reliability
†
Total print volume: 10,000 pages(A4, Letter)
†
Print Head Life: 2000 million dots/nozzle
1.2.11 Safety Approvals
†
120V version
„
Safety standard: UL1950 with D3
CSA22.2 No.950 with D3
„
EMI: FCC part 15 subpart B classB
CSA C108.8 class B
†
220-240V version
„
Safety standard: EN60950(VDE, NEMKO)
EN55022(CISPR Pub.22) class B
AS/NZS 3548 class B
1.2.12 Acoustic noise
†
Level: Approx. 47 dB(A) (According to ISO 7779)
