-32-
23 LTI_LEVEL 1/1/0/0 0 ~ 3 NT,NT443,PAL,SECAM,PALM,PALN,480i,575i/ 480p,575p / 1080i60,1035i,720p/ 1080i50
24 D_PIC 0/0/1/1 0 ~ 3 NT,NT443,PAL,SECAM,PALM,PALN,480i,575i/ 480p,575p / 1080i60,1035i,720p/ 1080i50
25 HUE 31/31/31 0 ~ 63 PAL,PALM,PALN,PAL60,SECAM/ 575i,575p, only possible to adjust in these mode
26 SUB_COL 7/7/7/8/6/9 0 ~ 15 NT,NT443/PAL,PALM,PALN,PAL60,SECAM/480i,480p/575i,575p/1035i/1080i,720p
27 SUB_HUE 7/7/8/7/9/6 0 ~ 15 NT,NT443/PAL,PALM,PALN,PAL60,SECAM/480i,480p/575i,575p/1035i/1080i,720p
28 CINEMA CTI_LEVEL 2
29 CINEMA LTI_LEVEL 0
Group:4 L3E07050
0 G_SUB_BRT 0/0 0 ~ 1023 PC/DVI,AV_502
1 B_SUB_BRT 0/0 0 ~ 1023 _902
2 R_SUB_BRT 0/0 0 ~ 1023 _102
3 G_SUB_GAIN 367/390/300/420 0 ~ 1023 PC/AV/DVI/HD _501 ✻ G-PC Gainl Adjustment
4 B_SUB_GAIN 367/390/300/420 0 ~ 1023 Data of Gamma at point 980 is set 500 temporary when entering the mode._901 ✻ B-PC Gainl Adjustment
5R_SUB_GAIN 367/390/300/420 0 ~ 1023 _101 ✻ R-PC Gainl Adjustment
6 Standard G GAMMA SHIFT 390/390 0 ~ 1023 _503 PC,DVI std/AV StdCenter 512 * Change RGB data at same time when changing G.✻ Luminance Adjustment
7 Standard B GAMMA SHIFT 390/390 0 ~ 1023 _903 PC,DVI std/AV Std Center 512 ✻ R-White Balance Adjustment
8 Standard R GAMMA SHIFT 390/390 0 ~ 1023 _103 PC,DVI std/AV Std Center 512 ✻ B-White Balance Adjustment
9 Standard GAMMA 0 0/0 0 ~ 1023
10 Standard GAMMA 1 150/140 0 ~ 1023 PC,DVI Standard / AV Standard
11 Standard GAMMA 2 253/245 0 ~ 1023 Read only
12 Standard GAMMA 3 359/367 0 ~ 1023
13 Standard GAMMA 4 448/460 0 ~ 1023
14 Standard GAMMA 5 524/522 0 ~ 1023
15 Standard GAMMA 6 598/599 0 ~ 1023
16 Standard GAMMA 7 643/645 0 ~ 1023
17 Standard GAMMA 8 680/680 0 ~ 1023
18 Standard GAMMA 9 708/708 0 ~ 1023
19 Standard GAMMA 10 736/735 0 ~ 1023
20 Standard GAMMA 11 766/764 0 ~ 1023
21 Standard GAMMA 12 801/796 0 ~ 1023
22 Standard GAMMA 13 844/840 0 ~ 1023
23 Standard GAMMA 14 920/885 0 ~ 1023
24 Standard GAMMA 15 1023/980 0 ~ 1023
25 Real/Cinema G GAMMA SHIFT 506/506 0 ~ 1023 _503 Difference PC,DVI Real / AV Cinema(Difference from Standard)
26 Real/Cinema B GAMMA SHIFT 502/502 0 ~ 1023 _903 Difference
27 Real/Cinema R GAMMA SHIFT 512/512 0 ~ 1023 _103 Difference
28 Real/Cinema GAMMA 0 512/512 0 ~ 1023
29 Real/Cinema GAMMA 1 528/527 0 ~ 1023 PC,DVI Real / AV Cinema(Difference from Standard)
30 Real/Cinema GAMMA 2 527/521 0 ~ 1023
31 Real/Cinema GAMMA 3 525/519 0 ~ 1023
32 Real/Cinema GAMMA 4 523/516 0 ~ 1023
33 Real/Cinema GAMMA 5 519/215 0 ~ 1023
34 Real/Cinema GAMMA 6 515/510 0 ~ 1023
35 Real/Cinema GAMMA 7 510/208 0 ~ 1023
36 Real/Cinema GAMMA 8 505/508 0 ~ 1023
37 Real/Cinema GAMMA 9 503/503 0 ~ 1023
38 Real/Cinema GAMMA 10 501/501 0 ~ 1023
39 Real/Cinema GAMMA 11 499/499 0 ~ 1023
40 Real/Cinema GAMMA 12 496/496 0 ~ 1023
41 Real/Cinema GAMMA 13 492/492 0 ~ 1023
42 Real/Cinema GAMMA 14 488/488 0 ~ 1023
43 Real/Cinema GAMMA 15 512/512 0 ~ 1023
44 r_mid2_level 464 0 ~ 1023 _C9D
45 r_mid1_level 560 0 ~ 1023 _C9E
46 r_max_level 632 0 ~ 1023 _C9F
47 g_mid2_level 464 0 ~ 1023 _CA1
48 g_mid1_level 560 0 ~ 1023 _CA2
49 g_max_level 632 0 ~ 1023 _CA3
50 b_mid2_level 464 0 ~ 1023 _CA5
51 b_mid1_level 560 0 ~ 1023 _CA6
52 b_max_level 632 0 ~ 1023 _CA7
53 Correction for Vertical line R2 0 0 ~ 255 _C48
54 Correction for Vertical line G2 0 0 ~ 255 _C4D
55 Correction for Vertical line B2 0 0 ~ 255 _C52
56 Coorection for R-ghost 8 0 ~ 2047 _C58
57 Coorection for G-ghost 8 0 ~ 2047 _C58
58 Coorection for B-ghost 8 0 ~ 2047 _C58
Group:5 DAC
0 G_VIDEO_CENTER 120 0 ~ 255 dac1 ✻ G-Video Center Adjustment
1 B_VIDEO_CENTER 120 0 ~ 255 dac1 ✻ B-Video Center Adjustment
2R_VIDEO_CENTER 120 0 ~ 255 dac1 ✻ R-Video Center Adjustment
3 REF_G 60 0 ~ 255 dac1 ✻ G-Black Level Adjustment
4 REF_B 60 0 ~ 255 dac1 ✻ B-Black Level Adjustment
5 REF_R 60 0 ~ 255 dac1 ✻ R-Black Level Adjustment
6 NRSB 160 0 ~ 255 NRSB ✻ NRS Adjustment
7 NRSA 40 0 ~ 255 NRSA ✻ NRS Adjustment
8 G_V_COM 55 0 ~ 255 dac2 ✻ G Common Center Adjustment
9 B_V_COM 55 0 ~ 255 dac2 ✻ B Common Center Adjustment
10 R_V_COM 55 0 ~ 255 dac2 ✻ R Common Center Adjustment
11 G_CLMP 90 / 95 0 ~ 255 PC/AV ✻ G-Pedestal Adjustment
12 B_CLMP 90 / 95 0 ~ 255 It differs the control port in PC and AV ✻ B-Pedestal Adjustment
13 R_CLMP 90 / 95 0 ~ 255 ✻ R-Pedestal Adjustment
14 G_BLK_DC 80/80/80 0 ~ 255 AV Pedestal Adjustment video/1080i,1035i,720p/480p,525p
15 B_BLK_DC 80/80/80 0 ~ 255 AV Pedestal Adjustment video/1080i,1035i,720p/480p,525p
Electrical Adjustments
No. Adjustment Item Initial Value Range Input source / Description
