DXS/DWS 3200 Series User Guide
Page 46
16. From the Stack menu, press “4”. The Startup menu is displayed.
17. From the Startup menu, press “10”. The Startup menu is closed and the device continues the Startup process.
Note
Once the device is booted up and operational in the stack, the configuration can be modified through the
Web or CLI.
Startup Menu Functions
Additional configuration functions can be performed from the Startup menu.
To display the Startup menu:
1. During the boot process, after the first part of the POST is completed press
<Esc> or <Enter> within two sec-
onds after the following message is displayed:
The Startup menu is displayed and contains the following configuration functions:
The following sections describe the Startup menu options. If no selection is made within 25 seconds (default), the
switch times out and the device continues to load normally.
Only technical support personnel can operate the Diagnostics Mode. For this reason, the
Enter Diagnostic Mode
option of the Startup menu is not described in this guide.
Download Software
Use the software download option when a new software version must be downloaded to replace corrupted files,
update, or upgrade the system software.
To download software from the Startup menu:
1. On the Startup menu, press “1”.
The following prompt is displayed:
2. When using HyperTerminal, click
Transfer on the HyperTerminal menu bar.
3. From the Transfer menu, click
Send File. The Send File window is displayed.
4. Enter the file path for the file to be downloaded.
5. Ensure the protocol is defined as Xmodem.
6. Click
Send.
The software is downloaded. Software downloading takes several minutes. The terminal emulation applica-
tion, such as HyperTerminal, may display the progress of the loading process.
After software downloads, the device reboots automatically.
Autoboot in 2 seconds -press RETURN or Esc.to abort and enter prom.
Startup Menu
[1]Download Software
[2]Erase Flash File
[3]Erase Flash Sectors
[4]Password Recovery Procedure
[5]Enter Diagnostic Mode
[6]Stack Menu
[7]Back Enter your choice or press 'ESC' to exit:
Downloading code using XMODEM
