FAN STYLES > CONTRACTOR
Ceiling Drop Dimensions
Features
Specs
182
The Cecilia features styling and detail one doesn’t usually
associate with Contractor fans.
Cecilia
™
Ceiling Drop Dimensions
Blade Sweep Opt. 42", 52"
Number of Blades 5
Blade Pitch 12˚
Motor Size (MM) 153 x 12
AMPS (HI Speed) 0.6
Watts (HI Speed) 63
RPM (HI-MED-LOW) 162-117-73
Shipping Wt. (lbs.) 18
CU. FT. in Carton 1.6
Airflow*
(Cubic Feet Per Minute)
5156
Electricity Use* 63 Watts
Airflow Efficiency*
(Cubic Feet Per Minute
Per Watt)
81
Brushed Nickel Cecilia with 52" Contractor's Design Walnut Blades
Model-Finish CC52BN
Blade-Finish BCD52-WB6
Light-Finish Not Shown
B
E
D
C
C
A
A: 2" DR - 12.25" B: 2" DR - 8.0"
A: 4" DR - 15.5" B: 4" DR - 12.0"
C: 12.0" D: 5.125"
E: 4.25"
DR: Downrod
“Compare: 36" to 48" ceiling fans have airflow efficiencies
ranging from approximately 71 to 86 cubic feet per minute
per watt at high speed.”
“Compare: 49" to 60" ceiling fans have airflow efficiencies
ranging from approximately 51 to 176 cubic feet per
minute per watt at high speed.”
Standard, 3 Speed Reversible
Motor
2" and 4" Downrods (Included)
30 Year Limited Warranty
Blades Sold Separately
Light Kit Adaptable (Optional)
Universal Control Adaptable
(Optional)
Additional Blade Selections In 42"
Size Available
See Page 310
