Specifications
10 Rev 20070227-59
Specifications
Performance Specifications
Rated Pull 10,000 lbs (4536 kg)
Gear Reduction Ratio 294:1
Motor Series Wound Motor
3.6 HP/2.7 KW (DC 12V)
Drum Size 2.48” (D) x 9” (L)
63 mm (D) x 228.6 mm (L)
Cable 3/8” (D) x 85’ (L)
9.53 mm (D) x 25.9 m (L)
(over 79 useable feet with five
wraps on the winch drum)
Weight 80.5 lbs. (36.51 kg)
Height 10.63 inches (270 mm)
Width 7.1 inches (180.34 mm)
Length 22.4 inches (568.96 mm)
Bolt Pattern 10” x 4.5”
(254 mm x 114.3 mm)
Line speed and Motor Current (First layer)
lbs 0 2000 4000 6000 8000 10000
Line pull Max
kgs 0 907.2 1814.4 2721.6 3628.7 4536
FPM 24 13 9 7 5.6 4.6 Line speed
(12VDC)
MPM 7.3 4.0 2.7 2.1 1.7 1.4
Max Current amps 80 150 170 210 250 300
Cooling Time minutes 5 5 5 5 5 5
Line pull and cable capacity
Layers of cable on drum 1 2 3 4
lbs 10000 8000 6600 5600 Max pulling capacity per
layer
kgs 4536 3629 2994 2540
ft 18 39.4 64 85 Cable capacity
per layer
m 5.5 12.0 19.5 25.9
* Use double line and snatch block for pulling loads over 8,000lbs / 3628.7kgs.
