Joining an existing Network
In this scenario a network has already been established with multiple
devices, A and B. You want to add a new device, C. Any of the existing
devices on the network can act as the host to allow C to join the
network. Follow these steps below.
1. Plug in the device C on the same power system as device A and B.
2. Press the encryption key on the device C for 10 seconds until the
unit’s LED’s flash and the unit resets.
3. Wait for 30 seconds for the reset to be complete.
4. Press the encryption button on the existing device (A or B) for 3
seconds or less, it will then enter host mode.
5. Press the encryption button on the new device C for less than 3
seconds. This must be done within one minute of step 4.
6. The new adapter should now join the existing network, simply wait for
the connection to be established.
The Power LED on both of the devices should flash at 1-second intervals
until the process has been completed, in success or failure. The Power
LED will be illuminated constant once the connection is established
successfully. If an error occurs, the Power LED on the device on the
existing network (A, B, or C in this example) will flash until the encryption
button on the existing device is pressed again.
