11. Lamp menu
11.4 Lamp Identification
About
The lamp identification menu gives an overview of the most important parameters of the used lamp.
These parameters are:
• Serial number lamp
• Article number of the used lamp
• Run time since first start up of the lamp
• Remaining run time for a safe operation of the lamp
• Number of strikes since the first start up of the lamp
These parameters are useful when calling for a service intervention.
How to display?
1. Press MENU to activate the menus.
2. Use the ▲ or ▼ key to select Lamp and press ENTER.
3. Use the ▲ or ▼ key to select Identification and press ENTER.
The identification overview is displayed.
Image 11-8
Image 11-9
Image 11-10
11.5 Z-axis adjustment
What can be done?
This menu item gives the current light output of the projector. This light output indication can be used to readjust the lamp position in
the lamp casing (also called Z-axis adjustment of the lamp). With higher run times, the light output of the lamp will decrease, which
results in a lower light output on the screen. This light output decrease can be compensated by readjusting the position of the lamp.
For the realignment procedure, see "Realignment of the lamp in its reflector", page 189.
How to display the light output
1. Press MENU to activate the menus.
2. Use the ▲ or ▼ key to select Lamp and press ENTER.
3. Use the ▲ or ▼ key to select Z-axis and press ENTER.
