ASUS P6T SE 2-15
Chapter 2
Side(s): SS - Single-sided DS - Double-sided
DIMM support:
• A*:
Supports two (2) modules inserted into slot A1 and B1 as one pair of
Dual-channel memory conguration.
• B*:
Supports three (3) modules inserted into the orange slots (A1, B1 and
C1) as one set of Triple-channel memory conguration.
• C*:
Supports four (4) modules inserted into the orange slots (A1, B1 and
C1) and the black slot A2 as one set of Triple-channel memory
conguration.
• D*:
Supports six (6) modules inserted into both the orange slots and the
black slots as two set of Triple-channel memory conguration.
• According to Intel spec denition, DDR3-1600 is supported for one DIMM per channel
only. ASUS exclusively provides two DDR3-1600 DIMM support for each memory
channel.
• Visit the ASUS website for the latest QVL.
Vendor Part No. Size
SS/
DS
Chip Brand Chip NO.
Timing DIMM
(BIOS)
Voltage
DIMM socket support
(Optional)
A* B* C* D*
MICRON MT16JTF25664AY-1G1D1 2GB DS MICRON 7VD22 7 • • • •
Qimonda IMSH1GU03A1F1C-10F
1GB
SS Qimonda
IDSH1G-03A1F1C-10F 7
• •
• •
Qimonda IMSH1GU03A1F1C-10G 1GB SS Qimonda IDSH1G-03A1F1C-10G 8 • • • •
Qimonda IMSH1GU13A1F1C-10F 1GB DS IDSH51-03A1F1C-10F • • • •
Qimonda IMSH2GU13A1F1C-10F 2GB DS Qimonda IDSH1G-03A1F1C-10F 7 • • • •
Qimonda IMSH2GU13A1F1C-10G 2GB DS Qimonda IDSH1G-03A1F1C-10G 8 • • • •
Transcend
TS256MLK64V1U
2GB DS
ELPIDA J1108BABG-AE-E
CL7
(1066-7-7-7-20)
•
• •
•
Aeneon AEH760UD00-10FA98X 1GB DS AENEON AEH93R10F 7 • • •
Asint SLY3128M8-EAE 1GB SS Asint DDRIII1208-AE (7-7-7-20) • • • •
Asint SLZ3128M8-EAE 2GB DS Asint DDRIII1208-AE (7-7-7-20) • • • •
Elixir M2F2G64CB8HAN4-BE 2GB DS Elixir N2CB1G80AN-BE 7 • • • •
WINTEC 3DU3191A-10 1GB DS Qimonda IDSH51-03A1F1C-10F 7 • •
P6T SE Motherboard
Qualied Vendors Lists (QVL) DDR3-1067MHz capability (continued)
