ASUS M2R-FVM 2-25
2.5.4 Hardware Monitor
The items in this sub-menu displays the hardware monitor values
automatically detected by the BIOS. Select an item then press <Enter> to
display the configuration options.
Select Menu
Item Specific Help
Hardware Monitor
CPU Temperature 40C
MB Temperature 33C
Vccp [Igored]
5V [Igored]
12V [Igored]
3.3V [Igored]
CPU FAN Speed 3300 RPM
Chassis FAN Speed 0 RMP
Fan Control [Enabled]
Phoenix-Award BIOS CMOS Setup Utility
Power
F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select SubMenu F10: Save and Exit
Vccp [Ignored]
Configuration options: [1.38V] [Ignored]
5V [Ignored]
Configuration options: [5.12V] [Ignored]
12V [2C]
Configuration options: [12.02V] [Ignored]
3.3V [Ignored]
Configuration options: [3.29V] [Ignored]
Fan Control [Enabled]
Enable/Disable the control of the system/CPU fun speed by changing the
fan voltage. Configuration options: [Enabled] [Disabled]
