ASUS M2N32-SLI Deluxe 5-43

PHYSICAL DRIVE

0 XXXXXXXXXXX XXXXXXMB

1 XXXXXXXXXXX XXXXXXMB

2 XXXXXXXXXXX XXXXXXMB

3 XXXXXXXXXXX XXXXXXMB

c. Repeat step b to select the target drive.

d. After selecting the

source and target

drives, the following

pop-up menu

appears.

Manual conguration

a. Select Manual

conguration and press

<Enter>. The selection

bar moves to the Physical

Drives menu.

b. Using the up or down arrow

keys, select the

source drive

and press <Enter>.

3. Select your desired method of conguration.

Auto conguration

a. Select Auto Conguration then press <Enter>.

b. The utility prompts a message to input the RAID size, use the up

or down arrow keys to set the RAID size then press <Enter>.

c. Press <Y> to conrm or <N> to return to the Main Menu.

• Auto-conguration creates a RAID 1 set without a backup copy of

the current source disk data.

• When migrating a single hard disk drive to a RAID 1 set, use of the

Manual conguration is recommended.

MAIN MENU

Auto conguration

Manual conguration

Create with data copy

Create without data copy

• The Create with data copy option allows you to copy the current

data from the source drive to the mirror drive.

• Select Create with data copy if you have important data in your

source drive.

• The Create without data copy option disables the disk copy function

of the Mirrored set.

• If you selected Create without data copy, the RAID 1 set must be

repartitioned and reformatted to guarantee the consistency of its

contents.
