61181300L1-5C Section 61181300L1-5C, Issue 3 13
Figure 8. Service State Screen
Shelf: Slot: 10 Total Access System 07/15/99 10:42
Unacknowledged Alarms: None
Service State
1. Port 0 Out of Service - Unassigned
2. Port 1 Out of Service - Unassigned
3. Port 2 Out of Service - Unassigned
4. Port 3 Out of Service - Unassigned
5. Port 4 Out of Service - Unassigned
Selection:
‘?’ - System Help Screen
Figure 7. Provisioning Screen
Shelf: Slot: 10 Total Access System 07/15/99 10:42
Unacknowledged Alarms: MINOR
Provisioning
1. Service State
2. All Provisioning
Selection:
‘?’ - System Help Screen
Accessing the QFO-C Provisioning Screen
1. From the Fiber Main Menu Screen, type “2” and
press Enter to select Provisioning. The Provisioning
Screen (Figure 7) will appear.
2. Type “1” and press Enter for the Service State of
the individual ports. The Service State Screen
(Figure 8) will appear.
