10 Issue 1, December 2003 61223424L2-5A
The Detailed Status Screen from the Span Status menu
(Figure 10), displays the HDSL4 status for each
receiver point.
The
Loopbacks and Test Commands menu (Figure 11)
provides the ability to invoke or terminate all available
HDSL4 loopbacks.
Each HDSL4 circuit component can be looped toward
the network or customer from this screen. Unit self tests
can also be initiated from this screen.
Figure 10. Detailed Status Screen
Figure 11. Loopbacks and Test Commands Menu
Circuit ID: 10/01/03 09:29:45
Press ESC to return to previous menu
Detailed Status Screen
LOOP 1 LOOP 2
MARGIN ATTEN MARGIN ATTEN
Interface (CUR/MIN/MAX) (CUR/MAX) (CUR/MIN/MAX) (CUR/MAX)
--------- ------------- --------- ------------- ---------
H4TUC 17/00/17 00/00 17/00/17 00/00
H4R1 NETW 17/00/17 00/00 17/13/17 00/00
H4R1 CUST 17/17/17 00/00 17/00/17 00/00
H4R2 NETW 17/00/17 00/00 17/13/17 00/00
H4R2 CUST 17/17/17 00/00 17/00/17 00/00
H4TUR 17/00/17 00/00 17/00/17 00/00
1. Reset Min/Max
2. View Performance History
Selection:
Circuit ID: 10/01/03 09:29:45
Press ESC to return to previous menu
Loopbacks and Test Commands
______ ______ ______ ______
NET | | | | | | | | CUST
| | | | | | | |
----->| |-------| |-------| |----------------------| |----->
| | | | | | | |
| | | | | | | |
<-----| |-------| |-------| |----------------------| |<-----
| | | | | | | |
DSX-1 |______| |______| |______| |______| DS1
H4TUC H4R 1 H4R 2 H4TUR
1. Run Self Tests 7. H4R1 Loopup Cust
2. H4TU-C Loopup Net 8. H4R1 Loopup Net
3. H4TU-C Loopup Cust 9. H4R2 Loopup Cust
4. H4TU-R Loopup Net
5. H4TU-R Loopup Cust
6. H4R1 Loopup Net
Selection:
