FS-100 Portable DTE Recorder
89
LCD Display Symbols and Text
The table below shows the different symbols and states displayed on
the top line of the LCD when used with different FS-100 control,
record, play and stop modes:
PLAY/REC MODE FS-100 LCD
Stop STOP
Pause ll PLAY
Play
PLAY
Rec (Pause) ll REC
Normal Rec (Rec) REC
PRE-REC Disk (Stop) P STOP
PRE-REC Disk (Standby) P REC
PRE-REC Cach (Stop) C STOP
PRE-REC Cach (Standby) C REC
Loop Record (Stop) L STOP
Loop Record (Standby) L REC
Loop Record (Rec) L REC
Snap (Stop) STOP
Snap (Standby) ll SNAP
Snap (Rec) ll SNAP
Time Lapse (Stop) STOP
Time Lapse (Pause) ll T REC
Time Lapse (Rec) T REC
AV/C* (Stop) A STOP
AV/C* (Rec Pause) ll A <REC TYPE> REC
AV/C* (Rec) A <REC TYPE> REC
AV/C* (Play Pause) ll A PLAY
AV/C* (Play) A ALL
Syncro Slave (Pause) ll Y <REC TYPE> REC
Syncro Slave (Rec) Y <REC TYPE> REC
PLAY/REC MODE FS-100 LCD
