User’s manual
VM310/VM310-13
Accessory baby unit
for use with VTech model
VM311/VM311-13/VM311-2/
VM311-23
Congratulations
on purchasing your new VTech product.
Before using this product, please read
Important safety instructions.
This manual has instructions on how to set
up and pair your new baby unit. For complete
instructions on using the baby unit, see the
user’s manual that came with your video and
audio monitor.
For support, shopping, and everything new at
VTech, visit our website at
www.vtechphones.com.
Register online to get an additional
3-month warranty!
Visit www.vtechphones.com.
Registration
Register your product online for
enhanced warranty support.
Product news
Learn about the latest VTech
products.
When using your equipment, basic safety
precautions should always be followed to reduce the
risk of fire, electric shock and injury, including the
following:
Follow all warnings and instructions marked on
the product.
Adult setup is required.
This product is intended as an aid. It is not
a substitute for responsible and proper adult
supervision and should not be used as such.
This product is not intended for use as a medical
monitor.
1.
2.
3.
4.
Do not use this product near water. For example, do
not use it next to a bath tub, wash bowl, kitchen sink,
laundry tub or swimming pool, or in a wet basement
or shower.
Use only the adapter included with this product.
Incorrect adapter polarity or voltage can seriously
damage the product.
Baby unit power adapter: Input 100-240V AC
150mA 50/60Hz; Output: 6V DC 600mA.
The power adapter are intended to be correctly
oriented in a vertical or floor mount position. The
prongs are not designed to hold the plug in place
if it is plugged into a ceiling, under-the-table or
cabinet outlet.
Unplug this product from the wall outlet before
cleaning. Do not use liquid or aerosol cleaners.
Use a damp cloth for cleaning.
Do not cut off the power adapter to replace it with
other plug, as this causes a hazardous situation.
Do not allow anything to rest on the power cords.
Do not install this product where the cords may be
walked on or crimped.
This product should be operated only from the
type of power source indicated on the marking
label. If you are not sure of the type of power
supply in your home, consult your dealer or local
power company.
Do not overload wall outlets or use an extension
cord.
Do not place this product on an unstable table,
shelf, stand or other unstable surfaces.
This product should not be placed in any area
where proper ventilation is not provided. Slots and
openings in the back or bottom of this product
are provided for ventilation. To protect them from
overheating, these openings must not be blocked
by placing the product on a soft surface such as
a bed, sofa or rug. This product should never be
placed near or over a radiator or heat register.
Never push objects of any kind into this product
through the slots because they may touch
dangerous voltage points or create a short circuit.
Never spill liquid of any kind on the product.
To reduce the risk of electric shock, do not
disassemble this product, but take it to an
authorized service facility. Opening or removing
parts of the product other than specified access
doors may expose you to dangerous voltages
or other risks. Incorrect reassembling can cause
electric shock when the product is subsequently
used.
You should test the sound reception every
time you turn on the units or move one of the
components.
Periodically examine all components for damage.
Be aware of possible loss of privacy while using
public airwaves. Conversations may be picked
up by other nursery monitors, cordless phones,
scanners, etc.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
Important safety
instructions
Use only the baby unit power adapter
supplied with this product.
The baby unit power adapter is intended
to be correctly oriented in a vertical or
floor mount position. The prong are not
designed to hold the plug in place if it is
plugged into a ceiling, under-the-table or
cabinet outlet.
Make sure the baby unit and the power
adapter cord are out of reach of children.
•
•
•
Connect the baby unit
1
Camera
2 Infrared LEDs
Backup light for night vision.
3
POWER on/off indicator
On when the baby unit is powered on
and currently linked to parent unit.
Flashes when the baby unit is not
linked to a parent unit; or
the pairing process is in progress; or
the parent unit is not viewing this baby
unit.
•
•
4
Power jack
5
Control key panel
/VOL
+
Press to increase the listening volume.
/VOL
-
Press to decrease the listening volume.
PAIR
Press and hold to pair to the parent unit.
(On/Off)
Press and hold to turn on or off.
6
Microphone
7
Stand
Tilt to adjust the camera angle.
8
Rim
9
Base
Overview
r
Baby unit
Power outlet not
controlled by a wall switch
Baby unit power adapter
Self-adhesive
strap
Part checklist
To keep this product working well and looking good,
follow these guidelines:
Avoid putting it near heating appliances and
devices that generate electrical noise (for example,
motors or fluorescent lamps).
DO NOT expose it to direct sunlight or moisture.
Avoid dropping the product or treating it roughly.
Clean with a soft cloth.
DO NOT immerse the baby unit in water and do
not clean them under the tap.
DO NOT use cleaning spray or liquid cleaners.
Make sure the baby unit is dry before you
connect them to the mains again.
•
•
•
•
•
•
•
General product care
Pair and replace extra new baby unit
Each newly purchased baby units (VM310/
VM310-13) must be paired to your video and
audio monitor system (VM311/VM311-13/
VM311-2/VM311-23).
You can pair a maximum of four baby
units to your parent unit. Each new baby
unit must be paired to the parent unit
before use.
Make sure you power on the parent unit
before pairing.
To pair and replace a baby unit:
Press MENU/SELECT when the parent unit is
not in use.
Press or to choose .
Press or to choose a desired baby unit
slot, then press MENU/SELECT. The screen
displays .
If you choose an occupied baby unit slot,
the new baby unit will replace the existing
baby unit.
4. Press and hold on the new baby unit
until the POWER light flashes.
Then immediately press and hold PAIR
until the POWER light turns on.
When pairing is successful, the screen displays
, and then the image from the newly paired
baby unit.
If pairing fails, the screen displays . Try
the pairing process again.
Only one baby unit can be paired at a time.
To unpair a baby unit:
Make sure you power on the baby unit and
the parent unit before unpairing the baby unit.
Press MENU/SELECT when the parent unit
is not in use.
Press or to scroll to .
Press or to select the desired baby unit
(1, 2, 3 or 4).
Press and hold TALK until and
display.
Press or to select to cancel, or to
confirm the unpair process.
Press MENU/SELECT to confirm your selection.
When unpairing is successful, the POWER
light on the selected baby unit flashes. The
parent unit displays for a while, and then the
image from the baby unit previously viewing.
•
•
1.
2.
3.
•
•
1.
2.
3.
4.
5.
6.
Before use
Positioning the baby monitor
Place the parent unit within the operating range
of the baby unit. We recommend the parent
unit is at least 3 feet away from the baby unit
to avoid audio feedback. If you still experience
audio feedback, move the parent unit and the
baby unit farther apart.
For better image quality, do not place the
baby unit too far away from your baby.
For desktop usage and/or wall mounting the
baby unit, you can refer to Installation guide.
Operating range
The operating range of the baby monitor is up
to 1,000 feet outdoors or 150 feet indoors. The
actual operating range may vary depending
on the environmental conditions and other
interferences such as walls, doors and other
obstructions.
Children should be supervised to ensure that they
do not play with the product.
The product is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
SAVE THESE INSTRUCTIONS
Cautions
Use and store the product at a temperature
between 32
o
F and 104
o
F.
Do not expose the product to extreme cold, heat
or direct sunlight. Do not put the product close to
a heating source.
Make sure the baby unit(s) and the adapter
cord(s) are always out of reach of the baby, at
least 3 feet away from the baby or crib, to avoid a
possible strangulation hazard.
Never place the baby unit(s) inside the baby’s
crib or playpen. Never cover the baby unit(s) with
anything such as a towel or a blanket.
Other electronic products may cause interference
with your baby monitor. Try installing your baby
monitor as far away from these electronic devices
as possible: wireless routers, radios, cellular
telephones, intercoms, room monitors, televisions,
personal computers, kitchen appliances and
cordless telephones.
Precautions for users of implanted cardiac
pacemakers
Cardiac pacemakers (applies only to digital cordless
devices):
Wireless Technology Research, LLC (WTR), an
independent research entity, led a multidisciplinary
evaluation of the interference between portable
wireless devices and implanted cardiac pacemakers.
Supported by the U.S. Food and Drug Administration,
WTR recommends to physicians that:
Pacemaker patients
Should keep wireless devices at least six inches
from the pacemaker.
Should NOT place wireless devices directly over
the pacemaker, such as in a breast pocket, when
it is turned ON.
WTR’s evaluation did not identify any risk to
bystanders with pacemakers from other persons
using wireless devices.
Electromagnetic fields (EMF)
This VTech product complies with all standards
regarding electromagnetic fields (EMF). If handled
properly and according to the instructions in this
user’s manual, the product is safe to be used based
on scientific evidence available today.
20.
21.
1.
2.
3.
4.
5.
•
•
