Interact-TV 44030 Baby Toy User Manual



Web site: www.interactivetoy.com
PLEASE! DO NOT RETURN THIS
PRODUCT TO ANY RETAIL STORE!
PLEASE! DO NOT RETURN THIS
PRODUCT TO ANY RETAIL STORE!
For any questions or problems with this product please contact us at:
Email: info@interactivetoy.com
Phone: Inside North America: +1-416-444-6873 Outside North America: 1-866-214-2220
Address: Interactive Toy Concepts, 1192 Martin Grove Road, Toronto, Ontario, Canada. M9W 5M9
IMPORTANT SAFETY INFORMATION
FCC NOTE: U.S. ONLY
INDUSTRY CANADA NOTICE: CANADA ONLY
Duck Hunter Xtreme is a registered trademark of Interactive Toy Concepts Limited.
© 2009. All Rights Reserved. Manufactured by and distributed by InteractiveToy Concepts Limited (HK).
Patent Information: EU: EP1958681 US: US2008191100 Canada: CA2607358 Aus: AU2007231617
Products and colors may vary. MADE IN CHINA.
INS-44030-100422-US
8+
Item# 44030
Congratulations on
your purchase of the
DUCK HUNTER
XTREME
IMPORTANT BATTERY INFORMATION:
Do not mix old and new batteries, different types of batteries, standard carbon zinc, alkaline or rechargeable of
different capacities. Rechargeable batteries are only to be charged under adult supervision. Please respect the
correct polarity (-) or (+). Do not try to recharge non-rechargeable batteries. Do not throw batteries into the fire.
Replace all batteries of the same type/brand at the same time. The supply terminals are not to be short-circuited.
Remove exhausted batteries from the toy. Batteries should be replaced by adults. Remove batteries if the toy is
not going to be played with for some time. The packaging should be kept since it contains important information.
Limited 30-day warranty
Product is warranted by Interactive Toy Concepts Limited against manufacturing defects
in material and workmanship under normal use for (30) days from the date of purchase.
Warranty is validated upon receipt of proof or purchase
and confirmation of UPC code.
Proof of Purchase
The Duck Hunter Xtreme is a revolutionary new toy that brings a greater
challenge to the learning experience of hunting a duck in the complete
safety of a virtual environment. An evolution of the popular Duck Hunter,
the Duck Hunter Xtreme is a 2 or more player game which
combines
the fun of hunting a virtual duck as well as radio controlled flight of the world’s
most responsive and reliable “ornithopter”. The Duck Hunter Xtreme blaster
uses a narrow infra-red (IR) beam to shoot down a fully functional, flying RC
ornithopter duck. The duck will fly for up to 10 minutes from a 20-30 minute charge.
The body of the duck is made of an ultra-light and flexible foam which provides
excellent structure and resistance to damage during hard falls. Fly the Duck Hunter
Xtreme indoors or outdoors. It takes 3 direct hits from the infra-red blaster to defeat
the flying duck. As an activity, the Duck Hunter Xtreme is very versatile. It is possible
for two or more players to enjoy a competitive game-play or for one player to practice
the RC flight of the duck without the shooting aspect and marvel at the flight of this
patented mechanical device.
INSTRUCTION MANUAL
1 Charger/
Display Stand
Do not modify your Duck Hunter Xtreme! Do not point the antenna directly at the Duck! Do not use in strong winds, use only in VERY mild conditions! Do
not use in rain, snow or around heavy debris! Do not use near electrical lines or electricity! Do not use around smoke or flames! Do not use around water!
Do not use in crowded areas! Do not use around air conditioning! Do not use around air vents! Do not use around ceiling fans! Do not use around large
obstacles! Do not use in very small spaces! Do be conscious of changes in your area! Any changes or modifications to this product are strictly prohibited
and will void product warranty. Keep moving wings away from eyes, hands, hair and loose clothing. Always turn off your Duck Hunter Xtreme and
transmitter when not in use. Always remove batteries from transmitter during storage. Always replace transmitter with NEW alkaline batteries for optimal
performance. Keep your instruction manual for future reference. Only use the provided charger included with the Duck Hunter Xtreme to charge the
lithium polymer battery installed in the Duck Hunter Xtreme.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful
interference. 2) This device must accept any interference received including interference that may cause undesired operation. Warning: Changes or
modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These Limits are
designed to provide reasonable protection against harmful interference in a residential installation. This generates, uses and can radiate radio frequency
energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following
measures: - Reorient or relocate the receiving antenna - Increase the separation between the equipment and receiver - Connect the equipment to an
outlet on a circuit different from that to which the receiver is connected - Consult the dealer or an experienced radio/TV technician for help.
This radiocommunication device complies with all the requirements of Industry Canada Standard RSS-310. Operation is subject to the following two
conditions: 1) This device may not cause harmful interference. 2) This device must accept any interference received, including interference that may
cause undesired operation. Field Strength and measurement distance: 27.145MHz – 54.95 dBµV/m at 3 meters. 49.860MHz - 63.86 dBµV/m at 3 meters.
1. To obtain the most stable flight, use full throttle when launching.
2. To achieve a wave flight pattern once the duck has attained the desired altitude (8-10 feet), gently pulse the throttle.
3. To gain altitude in a confined area, it is easier to start climbing in a circle than in a straight line. Push the throttle (left stick) and apply
the right stick to either left or right in order for the duck to gain altitude in a small confined area.
4. The duck can also glide once it is in motion. By letting go of the throttle (left stick), the duck will glide in a natural flight simulation.
(Note: this may fool your opponent into thinking that the duck was hit by the IR beam).
5. Only fly the Vamp outdoors in calm, windless weather conditions with no precipitation.
6. For optimizing your flying experience, you can apply some light weight Mylar tape to trim your duck to fly straight. If your duck
always turns to the right side, you should put the tape on the left tip of the wing (as shown) to adjust the center of gravity (CG).
Do the reverse if the duck always flies to the left.
1 “DUCK HUNTER XTREME” Flying Duck
The Duck Hunter
Xtreme has been
carefully packaged to
avoid damage during
shipping.
PLEASE USE
CAUTION WHEN
UNPACKING.
TM
You can replace the original wings on your Duck Hunter Xreme if they become damaged. A new set of wings can be purchased by contacting
Interactive Toy Concepts listed above. To replace the wings, do the following:
1. Make sure the Duck and the Blaster are turned off.
2. Gently remove the far corner of the wing that is tethered to the body by a ball joint.
3. The leading (front) edge of the wing is a thin carbon fiber rod. Gently pull this rod out of the gear box mechanism housing at the front.
4. Installation of the new wing is the reverse of the wing removal procedure with the following minor difference.
5. The carbon fiber rod has a slight notch cut into its end so that it will only fit properly into gear box mechanism
housing one way. Use caution when inserting the carbon fiber rod. If it is not going in smoothly, it is misaligned.
REPLACING DUCK HUNTER XTREME MAIN WINGS
TIPS AND TRICKS
Transmitter
1 Infra-red Blaster/
Portable Charger
Ni-Cd Rechargeable
Batteries must be
recycled or disposed
of properly.
